UBNT 14° Beamwidth 8.5W IS-5AC Gigabit Network Bridge

Product Categories
Shenzhen Toptoday Network Co., Ltd.
Contact Now

UBNT 14° Beamwidth 8.5W IS-5AC Gigabit Network Bridge

  • 1
  • 2

Brand Name : UBNT

Model Number : IS-5AC

Place of Origin : Guangdong, China

MOQ : Negotiable

Price : Negotiable

Product name : IS-5AC

Use : outdoor

Type : Fiber Optic Transceivers

Networking Interface : 10/100/1000 Ethernet Port

Operating Temperature : -40 to 70° C (-40 to 158° F)

Power Supply : 24V, 0.5A Gigabit PoE Adapter

Warranty : 1 Year

Dimensions : 174 x 174 x150 mm

Weight : 725.7g (1.60 lb)

Max. Power Consumption : 8.5W

Contact Now

UBNT wireless network bridge IS-5AC Gigabit network bridge isolation interference replaceable antenna wireless managemen

IS-5AC Description:

IS-5AC

1.Is a shielded and protected network bridge.

2.The model adopts a die-cast aluminum alloy shell and its antennas can be interchanged.

3.This technology makes the communication beam between the device and the device better isolated, improves performance and stability.

3.And its throughput rate Up to 450Mbps or more, according to specific deployment and environmental needs.

4.The radio frequency beam shape can be adjusted by replacing the horn antenna.

5.The asymmetric horn antenna fundamentally reduces the sidelobe and extremely low reverberation leakage, making it perform better than drinking sidelobe radiation before and after.

Specification:

IS-5AC

Dimensions

174 x 174 x150 mm

Weight

 725.7g (1.60 lb)

Networking Interface

 (1) 10/100/1000 Ethernet Port

Enclosure

 Outdoor UV Stabilized Plastic

Max. Power Consumption

 8.5W

Power Supply

 24V, 0.5A Gigabit PoE Adapter (Included)

Power Method

 24V Passive PoE In (Pairs 4, 5+; 7, 8-)

Supported Voltage Range

 22 - 26V

Gain

 24 dBi

Beamwidth

 14°

Sidelobe Level

 -10 dB

Front-to-Back Ratio

 27 dB

Mounting

 Pole-Mount (Kit Included)

Wind Loading

 150 N @ 200 km/h (33.72 lbf @ 125 mph)

Wind Survivability

 200 km/h (125 mph)

ESD/EMP Protection

 ± 24kV Contact/Air

Operating Temperature

 -40 to 60° C (-40 to 140° F)

Operating Humidity

 5 to 95% Noncondensing

Certifications

 CE, FCC, IC

UBNT 14° Beamwidth 8.5W IS-5AC Gigabit Network BridgeUBNT 14° Beamwidth 8.5W IS-5AC Gigabit Network Bridge
